TypeModel No.MakerCountryConstruction
DateScale LengthArea of Use
K&E Model N4236
Keuffel & Esser
Black painted brass and German silver
General area measurement

Notes: "The ""N"" in N4236 appears to mean ""New"", as in new design but same function. This is still a fixed length planimeter, but it adopts the covered mechanism of the 620000 series that would come later. The advantages of the covered mechanism are that it stays dust-free, and the plastic wheel that sticks through the top covers allows the user to zero the planimeter without touching the tracing wheel and getting finger oil on it. "

Image 1

Image 2

Image 3

Image 4

Image 5

Image 6

Image 7

Image 8

Image 9

Image 10

Image 11

Image 12
