Steam Engine Indicator
Trill Steam Engine Indicator
Trill
USA
Brass
Unknown
N/A
Measuring the horsepower of steam engines

Notes: "A steam engine indicator is an instrument for creating a plot of pressure vs. piston displacement in a steam engine. A chart is wrapped around a cylinder which can rotate against a spring in one direction. A string connected to the piston rod is wrapped around that cylinder and rotates it as the piston moves. The pencil is driven by a piston which is exposed to the steam pressure. There is usually a series of levers between the piston and pencil to amplify its motion and draw a larger trace. The resulting plot can be measured to find the horsepower and efficiency of the steam engine. The Trill indicator was patented in 1912, and made in Corry, Pennsylvania."


Image 1




Image 2




Image 3




Image 4




Image 5




Image 6




Image 7




Image 8
